The d&b audiotechnik V10P loudspeaker is a high-performance, 3-way passive system engineered for precise and balanced sound reproduction. It features two 10-inch low-frequency drivers in a dipole configuration, complemented by a horn-loaded 8-inch midrange driver and a 1.4-inch compression driver, mounted on a rotatable constant directivity horn. This central 8-inch driver delivers enhanced vocal clarity due to its efficient horn design. The advanced bass-reflex enclosure supports extended low-frequency response across the full bandwidth. With symmetrical driver placement along the cabinet’s central axis, the V10P achieves uniform dispersion, offering 110 degrees horizontal and 40 degrees vertical coverage. The horn can be rotated for horizontal setups. Constructed from durable marine-grade plywood and finished with weather-resistant Polyurea coating, the V10P is built for versatility in both ground-stacked and flown configurations. The cabinet includes ergonomic handles and multiple M10 threaded inserts, allowing secure integration with d&b rigging solutions for flexible installation.
High performance 3-way passive point source loudspeaker
- Components 2 x 10″/8″/1.4″
- Dispersion 110° x 40°
- SPLmax 139 dB
- Weight 33 kg / 75 lb
The d&b audiotechnik V10P is a compact yet powerful 3-way passive point source loudspeaker, designed to deliver consistent audio performance across a wide range of professional applications. Featuring two 10-inch low-frequency drivers in a dipole configuration, an 8-inch horn-loaded midrange driver, and a 1.4-inch compression driver mounted to a rotatable constant directivity horn, the d&b audiotechnik V10P offers precise control of dispersion and exceptional clarity in the vocal range. Its symmetrical driver layout ensures uniform coverage and accurate imaging, making it particularly effective in environments that demand intelligibility and directional consistency.
Engineered for standalone use or as part of a larger V-Series system, the d&b audiotechnik V10P is suited for venues such as concert halls, theatres, corporate events, and fixed installations. It offers the flexibility to be ground stacked or flown, providing system designers with multiple configuration options. The cabinet is constructed from marine-grade plywood and finished with a robust Polyurea coating, offering durability and resistance to weather exposure. With its reliable acoustic performance and broad deployment potential, the d&b audiotechnik V10P serves as a versatile solution for professionals requiring high-fidelity, full-range sound reproduction in both touring and installation contexts.
