d&b audiotechnik

D25 amplifier

The d&b D25 amplifier is a 2 RU device designed to deliver optimised power output for compact, high-efficiency d&b mobile loudspeaker systems. Despite its size, the d&b D25 offers the same advanced DSP capabilities found in larger d&b amplifiers. Supported loudspeaker models are detailed in the firmware release notes. With a dynamic range of 112 dB (unweighted), the d&b D25 includes robust loudspeaker management, configurable filtering, user-defined equalisation, and adjustable delay. Energy-saving functions, efficient power handling, and automatic wake-up help reduce operational costs and support sustainability goals. The amplifier supports up to 16 audio input channels, comprising eight Milan inputs, four analogue connections, and four AES3 digital inputs. A switch mode power supply with automatic voltage adaptation and active Power Factor Correction ensures reliable operation under varied mains conditions. The d&b D25 integrates with the d&b Remote network via Ethernet using AES70 OCA, accessible through its web interface or the d&b R1 Remote control software.

Mobile specific four channel amplifier

  • Maximum output power 4 x 1800/900 W into 4/8 Ω
  • Maximum output voltage/current 120 Vpeak / 35 Apeak
  • Operating and Monitoring display, colour TFT touchscreen, 4.3″ / 480 x 272 pixel
  • Milan-enabled

Enquire now
Professional-Grade Amplification for High-Efficiency Mobile Loudspeaker Systems





The d&b D25 amplifier is a compact 2 RU unit engineered to deliver precise and efficient power for smaller high-performance d&b mobile loudspeaker systems. Combining space-saving design with full-scale digital signal processing, the d&b D25 is particularly suited to touring applications and smaller-scale installations where high power-to-size efficiency is required. It supports a comprehensive range of d&b loudspeakers, as specified in the amplifier firmware release documentation, and ensures consistent audio performance across varying system configurations.

Designed with professional users in mind, the d&b D25 integrates extensive loudspeaker management functions, including filtering, equalisation, and delay adjustment, all configurable via a browser-based interface or through the d&b R1 Remote control software. Its compatibility with Open Control Architecture via Ethernet enhances system integration for networked audio environments. The d&b D25 also aligns with evolving sustainability standards through intelligent energy management features and power-saving capabilities.

Equipped with 16 input channels, including Milan audio, analogue, and AES3 options, the d&b D25 ensures versatile connectivity for modern audio workflows. Its robust switch mode power supply with active Power Factor Correction allows for consistent and efficient operation, even under unstable mains conditions. As part of the wider d&b system ecosystem, the d&b D25 amplifier supports dependable performance in professional sound reinforcement scenarios where reliability, precision, and integration are essential.

High-Efficiency Power Output
Delivers optimised amplification for compact d&b loudspeaker systems, ensuring reliable audio performance in mobile and small-scale applications.
Comprehensive Signal Processing
Incorporates full DSP functionality including user-definable EQ, filtering, and delay settings, enabling precise loudspeaker control and system tuning.
Versatile Input Connectivity
Supports 16 input channels with Milan, analogue, and AES3 inputs, allowing flexible integration into a variety of audio system configurations.
Energy and Power Management
Features automatic wake-up, energy-saving functions, and Power Factor Correction to reduce power consumption and support operational sustainability.
